ACCEPTANCE RATE
• 98% or more
PROCESSING SPEED*
• UBA Pro2-BNF for Table Games: approx. 1.3 sec /
note
*Under the following operational conditions:
(1) Power Supply DC24.0V±1%
(2) Temperatur 23 ± 3°C
(3) Humiditry 40% ~ 65% RH
Depending on the installation environment and the
number of operation cycles, the product may not be
able to fulfill the original specifications
BANKNOTE SIZE
• Length: 120 – 165mm; Width: 62 – 77mm
BANKNOTE INSERTION DIRECTION
• 4 ways
DIMENSIONS & WEIGHT
UBA Pro2 BNF Table
• Outline Dimensions:
W124.0 x H527.1 x D426.7 (mm)
• Weight: Approx. 8.8kg
BARCODE ACCEPTANCE
• Not supported
INTERFACE
• USB (USB Specification Rev. 2.0 Compliance)
• Photo-Coupler Isolation, RS232C
POWER CONSUMPTION
• 24VDC +/+ 5%
